CRY3717-S01 Coupler Set
CRY3717-S01 is a 6cc coupler set specifically designed for acoustic testing of circumaural headphones.
The unique design of CRY3717-S01 allows for electroacoustic measurements of headphones and audiometers, enabling comparisons and reproducibility across different product designs.
Technical Specifications
Nominal Sensitivity
50mV/Pa, -26±1.5dB re 1V/Pa
Frequency Response
100Hz to 8kHz±2dB
Dynamic Range
12dB to 134dB
Standards
IEC60318-3
Equivalent Volume
6cc
Weight
693g
Main Features
- Compliant with IEC 60318-3 standard
- Extensive compatibility
- Durable, reliable, and high-quality
Product Highlights
CRY3717-S01 Ear Simulator Set Typical Frequency Response
The graph (right) shows the frequency response curves obtained using the electrostatic excitation method.
