Measure Sound Better

The CRY721C Pneumatic Shielded Isolator is primarily designed for power, sensitivity, and electrical performance testing of large wireless electronic products and communication devices, including headsets, wireless servers, and laptops with intercom capabilities. This shielding box is compatible with comprehensive testers, vector network analyzers, signal sources, and channel emulators to perform essential test items. Additionally, it supports a variety of wireless production devices such as Bluetooth, WiFi, GSM, WCDMA, RFID, GPS car remote controls, and more.

CRY721C Pneumatic Acoustic Test Chamber

This shielding box is compatible with comprehensive testers, vector network analyzers, signal sources, and channel emulators to perform essential test items. Additionally, it supports a variety of wireless production devices such as Bluetooth, WiFi, GSM, WCDMA, RFID, GPS car remote controls, and more.

Points forts du produit

Features

External vibration can be minimized for calibrating ANC.
Features RF shielding for Bluetooth® and WiFi testing.
Provides soundproofing environment for various test scenarios.
Control pneumatically through serial feed-through.
CRY613 ANC loudspeaker available for calibration.

Caractéristiques techniques

Color

White

Weight

About 155kg

Outer dimension

950(L)*700(W)*700(H)mm

Inner dimension

800(L)*550(W)*550(H)mm

Operating voltage

AC 100-240V, 50/60Hz

Rated power

15W

Pneumatic pressure

>5kg/cm2

RF shielding performance

0.8～6 GHz>70 dB (Without I/O interface)

Sound isolation performance

100Hz～125Hz>20dB, 160Hz～250Hz>30dB, 315Hz～400Hz>35dB, 500Hz～800Hz>40dB, Above 1000Hz>45dB (1/3 octave)

Noise floor

40 dBA, exterior noise≤80dBA (No shock or vibration)
